Máy Dập Hơi
Dập 500 tấn Kawasaki
Giá liên hệ
| Main Press | |
| Capacity | |
| Low Speed | 100～500 ton |
| High Speed | 40～200 ton |
| Automatic | 260～500 ton |
| Pressure Adjusting Range | 42.4～212 kg/cm2 |
| Rising Capacity | 37t / 212 kg/cm2 |
| Stroke | 1,000 mm |
| Daylight | 1,800 mm |
| Shut Height | 800 mm |
| Bolster | 3,500 X 1,800 mm |
| Slide | 3,500 X 1,800 mm |
| No Load Decending Speed | 260 mm/s |
| Speed Under Pressure | |
| High Speed | 80 mm/s (140t)～57 mm/s (200t) |
| Low Speed | 32 mm/s (350t)～22 mm/s (500t) |
| Automatic | 22 mm/s |
| Raising Speed | |
| Main Press only | 260 mm/s |
| Up thrust press | 170 mm/s |
| Number of presses | |
| Main Press | 1 x 300 ton |
| Side Press | 2 x 100 ton |
| Balancer Press | |
| Capacity | 120 ton |
| Pressure | 212 ton |
| Stroke | 1000 mm |
| Cylinders | 2 x 60 ton |
| Cushion Press | |
| Capacity | 30～150 ton |
| Pressure | 41.4～207 kg/cm2 |
| Stroke | 300 mm |
| Cushion Pad | 3,000 X 1300 mm |
| Quantity | 2 x 75 ton |
| Up Thrust Press | |
| Capacity | 15 ton |
| Pressure | 105 kg/cm2 |
| Raising Speed | 170 mm/s |
| Stroke | 300 mm |
| Quantity | 1 |
| Moving Bolster | |
| Pressure | 45kg/cm2 |
| Bolster Size | 3,500 X 1,800 mm |
| Bolster Traverse Speed | 60 mm/s |
| Max Load when moving | 55 ton |
| Bolster Stroke | 2,100 mm |
| Bolster Movement | Front Movement |
| Cylinders | 1 |
